ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter

ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter
ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter

Large Image :  ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter

Product Details:
Place of Origin: Qingdao
Brand Name: XINCHENG
Certification: SGS CCS LR BV RS ISO9001
Model Number: 50Kpa 80Kpa
Payment & Shipping Terms:
Minimum Order Quantity: 1piece
Price: $200-12000/piece
Packaging Details: deflated nude packing
Delivery Time: 15days
Payment Terms: MoneyGram, Western Union, MoneyGram
Supply Ability: 150PCS per month

ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter

Description
Size: Customized Size,D= 0.5m To 8m L= 1m To 12m,3.3x6.5m Type: Marine Air Bag/Pneumatic Yokohama Rubber Fender
Warranty: 24 Months Packing: Nude Packing/As Requirement
Initial Pressure: 0.05Mpa/0.08Mpa,50kPa Main Material: Natrual Rubber And Rubberized Cord Fabric
High Light:

ISO9001 Yokohama Ship Fenders

,

ISO9001 Large Yacht Fenders

,

Yokohama Ship Fenders 3.3m

Inflatable 3.3m Diameter Pneumatic Rubber Fender , Ship Floating Fender For Protection



inflatable 3.3m diameter pneumatic rubber fender , ship floating fender for protection



Pneumatic rubber fender is the advanced anti-collision device for marine application in the world. Pneumatic Rubber Fender also known as floating fender or Yokohama type rubber fender, it is often installed on the terminal or ship, which aims to absorb or reduce the collision energy between ship to ship and ship to dock. This kind of product can protect the ship or dock from the damage of collision. With inner compressed air, it can float on the water and widely used as protecting medium equipment. Size : D0.5 m x L1.0 m ~ D 3.3 x L6.5m. "XINCHENG" Pneumatic rubber fenders are produced in strict accordance with the ISO17357-2002 and GB/T 2002-2002 international quality standard, our products have exported to all over the world.
ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter 0

Compared to traditional solid rubber fender, pneumatic has following advantages
1. Big energy/ impact absorption capacity, small reaction force to ships
2. Easy and fast installation
3. Higher elasticity. It doesn’t get deformation under compression
4. Light weight
5. Economical and practical


ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter 1

a. Outer Rubber
Cover outside on the ball of rubber layer, which is used to protect skeleton material and inner rubber ball from damage of external force, the main features: high strength, wear resistance, ageing resistance and tear resistance.
b. Synthetic cord reinforced rubber layer
Reinforced cord rubber layer is composed of winding Synthetic cord layer, It is mainly used for maintain the internal air pressure, which has good elasticity, no deformation and high power etc.
c. Inner Rubber
On the ball inside the rubber layer, which is used to prevent air leakage and control the ball pressure.
d. End Flange
The metal parts at both ends of fender, which can be fitted with charging valve and safetyvalve.


ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter 2







Normal size

Diameter x Length


Initial Internal pressure 0.05MPa
Initial Internal pressure 0.08MPa



Guaranteed Energy Absorption(GEA)
Reaction Force At GEA(RF)
Hull Pressure At GEA(PR)



Guaranteed Energy Absorption(GEA)
Reaction Force At GEA(RF)
Hull Pressure At GEA(PR)
mm x mm

KN/M

KN
Kpa

Kpa

Kpa
Kpa
500x1000
6 64 132 8 83 174
600x1000
8 74 126 11 96 166
700x1500
17 137 135 24 178 178
1000x1500
32 182 122 44 235 161
1000x2000
45 257 132 63 335 174
1200x2000
63 297 126 86 386 166
1350x2500
102 427 130 140 554 170
1500x3000
153 579 132 211 751 175
1700x3000
191 639 128 263 830 168
2000x3500
308 875 128 424 1138 168
2500x4000
663 1381 137 925 1815 180
2500x5500
943 2019 148 1317 2653 195
3000x5000
965 1815 148 1341 2359 198
3300x4500
1175 1884 130 1640 2476 171
3300x6500
1814 3015 146 2532 3961 191

NOTE:1.REACTION FORCE AND ENERGY ABSORPTION TOLERANCE IS ±10%

2.WEIGHT TOLERANCE IS ±10%

3.SPECIAL SIZE CAN BE PRODUCED FOLLOW CUSTOMER'S NEEDS

 Tyre-chain Protective Jacket Type Pneumatic Fender



ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter 3

ISO9001 Yokohama Ship Fenders Large Yacht Fenders 3.3m Diameter 4
