Product Details:
|
| Product Name: | Marine Airbag,Ship Launching Marine Air Bag,Ship Launching Airbag,Inflatable Marine Rubber Airbag For Ship Launching Made In China,Marine Rubber Airbags For Launching And Docking Ships | Usage: | Ship Launching,ship Rubber Marine Salvage Lift Bags,marine Rubber Airbag,lifting Airbags |
|---|---|---|---|
| Warranty: | 2 Years | Size: | Customized Size,Customer's Ruquirement,Depend On Your Need,Dia1.5*9M |
| Standard: | ISO14409,CB/T-3837;ISO14409,CB/T-3795 | Layer: | 5/ 6/ 7 / 8 / 9 / 10 Layers |
| Packing: | Folded Into Tray | Long: | 8--24M |
| High Light: | Tugboat Inflatable Marine Airbags,Tugboat Heavy Lift Air Bags,Inflatable Marine Airbags 2.0m Diameter |
||
Tugboat Inflatable Airbag , Heavy Lift Air Bags With 2.0m Diameter
Marine ship airbags are also known as air balloon, inflatable bags, roller bags, air lifting bags, salvage bags. Airbags now are used for ship launching, loading, and floating. They are widely used in cargo boat/ship/vessel launching and landing, lifting and moving sunken ships, and salvaging stranded boats. Air bags have the benefit of not only saving labor and time, but investment costs. Additionally they are flexible, portable, and dependable. Therefore, airbags are widely used in slipping of ships and boats of all sizes.
Applications:
1. Shipwreck salvage
2. Floating bridge and dock construction
3. Rescue and remove of wrecked ship
4. Can be used as pontoons for supporting docks and other floating structure.
Performances:
1. We adopt the most advanced winding process to increase the bearing capacity and moment resistant capacity of airbags.
2. Compared with traditional launching track, the advantages of airbags is more flexibility. They are characterized by high resistance, high gas tightness, ageing resistance, and corrosion resistance.
3. Easy to install and dismantle on the wharf and anchor mast.
4. Long service lifespan.
SPECIFICATION OF MARINE AIRBAG
| Some normal sizes of our marine airbags, other sizes are also available | |||
| Diameter(m) | Effective Length(m) | Layer | Pressure(MPa) |
| 1.0 | 10 | 5~6 | 0.07~0.10 |
| 1.0 | 12 | 5~6 | 0.07~0.10 |
| 1.0 | 15 | 5~6 | 0.07~0.10 |
| 1.2 | 10 | 5~6 | 0.08~0.12 |
| 1.2 | 12 | 5~6 | 0.08~0.12 |
| 1.2 | 15 | 5~6 | 0.08~0.12 |
| 1.5 | 12 | 5~8 | 0.08~0.16 |
| 1.5 | 15 | 5~8 | 0.08~0.16 |
| 1.5 | 18 | 5~8 | 0.08~0.16 |
| 1.5 | 20 | 4~8 | 0.08~0.16 |
| 1.5 | 24 | 5~8 | 0.08~0.16 |
| 1.8 | 12 | 5~8 | 0.08~0.15 |
| 1.8 | 15 | 5~8 | 0.08~0.15 |
| 1.8 | 18 | 5~8 | 0.08~0.15 |
| 1.8 | 20 | 5~8 | 0.08~0.15 |
| 1.8 | 24 | 5~8 | 0.08~0.15 |
| 2.0 | 18 | 6~10 | 0.08~0.18 |
| 2.0 | 20 | 6~10 | 0.08~0.18 |
| 2.0 | 24 | 6~10 | 0.08~0.18 |
| 2.5 | 18 | 7~10 | 0.07~0.13 |
| 2.5 | 20 | 7~10 | 0.07~0.13 |
| 2.5 | 24 | 7~10 | 0.07~0.13 |
