Lightweight Marine Floating Fenders With Polyurethane Foam Filled

Lightweight Marine Floating Fenders With Polyurethane Foam Filled
Lightweight Marine Floating Fenders With Polyurethane Foam Filled Lightweight Marine Floating Fenders With Polyurethane Foam Filled Lightweight Marine Floating Fenders With Polyurethane Foam Filled Lightweight Marine Floating Fenders With Polyurethane Foam Filled

Large Image :  Lightweight Marine Floating Fenders With Polyurethane Foam Filled

Product Details:
Place of Origin: Qingdao
Brand Name: XINCHENG
Certification: CCS SGS LR BV RS
Model Number: dia1.5*3.0m
Payment & Shipping Terms:
Minimum Order Quantity: 1piece
Price: $200-12000/piece
Packaging Details: tray
Delivery Time: 15days
Payment Terms: MoneyGram, Western Union, MoneyGram, T/T, L/C
Supply Ability: 150PCS per month

Lightweight Marine Floating Fenders With Polyurethane Foam Filled

Description
Color: Black,Customers' Requirments,Red,Orange,blue Certificate: CCS BV SGS RS
Warranty Period: 24 Months Diameter: 1.5m
Type: Floating Type: Foam,pvc Fender,foam Boat Fenders
High Light:

Lightweight Marine Floating Fenders

,

Marine Floating Fenders Polyurethane Foam Filled

,

Marine Floating Foam Filled Fenders

      Lightweight Solid EVA Floating Fenders With Polyurethane Foam Filled



Lightweight Marine Floating Fenders With Polyurethane Foam Filled 0

polyurethane floating fender is also a kind of compressed fender which builds outer protective layer with polyurethane, materials and adopts polyurethane foaming material or plastic foaming as buffer medium;the destructive effects on docks and ships will be reduced by the compression to absorb the impact energy from ships in the course of using polyurethane floating fender.


Xincheng Invented new foam fender manufacturing method with blind hole hydrophobic foam as core and polyurea as outer coating, which has following features:
The core material of foam filled fender is bind hole hydrophobic foam with light weight and good energy absorption capability. It wont absorb water even cracking
The polyurea protective coating has very good performance of anti collision, anti friction, compression resistance, oil proof, water proof and weather fastness.
The fender is made with flange and swivel for fast installation, customer could install it very fast without any professional guidance from experts.


Tyre net sheath: Receiving special treatment, the tyres all have the advantages of firmness, durability and a beautiful surface, which can extend the fender's service life. The structural form of the sheaths can be divided into chain & tyre net, rope & tyre net, wire & tyre net, chain & rubber hose net, etc, and all can be produced as per client's special request.
1. Polyurea protection layer has the resistance of friction, extrusion, oil, sea water and acid & alkali. Maintainness free, do not need check or air inflation during use, and its lifetime can up to 10 -15 years;
2.Reliable performance, convenient installation, aesthetic functionalism, no risk of explosion and high safety;
3. Strong floating performance, lower weight, excellent energy absorption, flexible install location without being influenced by tidal range;
4. Better energy absrption performance and lower reaction force. The increase of reaction force is obvious at 60% deflection;



规格/Specification 压缩变形量60% /Compression Deflection at 60%

直径

Diameter/ mm

长度

Length/mm

反力

Reaction Force/ KN

吸收能量

Energy Absorption / KN/M

300 500 38 1.8
400 800 56 2.6
500 1000 72 26
1000 1500 205 49
1000 2000 274 64
1200 2000 337 93
1500 3000 624 216
2000 3500 990 456
2500 4000 1680 918
3000 6000 2460 1695
4500 9000 19650 7860


备注: 1. 反力与吸能公差±10% 2.重量公差±10% 3.特殊尺寸可根据要求制造
NOTE: 1. Reaction force and Energy absorption tolerance is ±10%
2. Weight tolerance is ±10%
3. Special size can be produced follow customer’s needs.





FAQ

Q: What's the material of your EVA Foam Filled Fender products ?
A: the main raw material is light weight high elasticity foam imported from Korea.
Q: Are you factory or trading company ?
A: We are manufacturing factory, located in Jimo district,Qingdao city, 1 hour drive to Qingdao port and 40 minutes drive to Qingdao airport, which is convenient in transportation logistics.
Q: Is OEM service available ?
A: yes
Q: What's the delivery time and payment terms ?
A: Delivery time is based on product model and order quantity. normally it is around 7-15 working days.
The payment could paid by T/T, L/C, Western Union, Paypal, etc.
