|Color:||Black,Customers' Requirments,Red,Orange,blue||Certificate:||CCS BV SGS RS|
|Warranty Period:||24 Months||Diameter:||1.5m|
|Type:||Floating||Type:||Foam,pvc Fender,foam Boat Fenders|
Lightweight Marine Floating Fenders,
Marine Floating Fenders Polyurethane Foam Filled,
Marine Floating Foam Filled Fenders
Lightweight Solid EVA Floating Fenders With Polyurethane Foam Filled
polyurethane floating fender is also a kind of compressed fender which builds outer protective layer with polyurethane, materials and adopts polyurethane foaming material or plastic foaming as buffer medium;the destructive effects on docks and ships will be reduced by the compression to absorb the impact energy from ships in the course of using polyurethane floating fender.
Xincheng Invented new foam fender manufacturing method with blind hole hydrophobic foam as core and polyurea as outer coating, which has following features:
The core material of foam filled fender is bind hole hydrophobic foam with light weight and good energy absorption capability. It wont absorb water even cracking
The polyurea protective coating has very good performance of anti collision, anti friction, compression resistance, oil proof, water proof and weather fastness.
The fender is made with flange and swivel for fast installation, customer could install it very fast without any professional guidance from experts.
Tyre net sheath: Receiving special treatment, the tyres all have the advantages of firmness, durability and a beautiful surface, which can extend the fender's service life. The structural form of the sheaths can be divided into chain & tyre net, rope & tyre net, wire & tyre net, chain & rubber hose net, etc, and all can be produced as per client's special request.
1. Polyurea protection layer has the resistance of friction, extrusion, oil, sea water and acid & alkali. Maintainness free, do not need check or air inflation during use, and its lifetime can up to 10 -15 years;
2.Reliable performance, convenient installation, aesthetic functionalism, no risk of explosion and high safety;
3. Strong floating performance, lower weight, excellent energy absorption, flexible install location without being influenced by tidal range;
4. Better energy absrption performance and lower reaction force. The increase of reaction force is obvious at 60% deflection;
|规格/Specification||压缩变形量60% /Compression Deflection at 60%|
Reaction Force/ KN
Energy Absorption / KN/M
备注: 1. 反力与吸能公差±10% 2.重量公差±10% 3.特殊尺寸可根据要求制造
NOTE: 1. Reaction force and Energy absorption tolerance is ±10%
2. Weight tolerance is ±10%
3. Special size can be produced follow customer’s needs.
Q: What's the material of your EVA Foam Filled Fender products ?
A: the main raw material is light weight high elasticity foam imported from Korea.
Q: Are you factory or trading company ?
A: We are manufacturing factory, located in Jimo district,Qingdao city, 1 hour drive to Qingdao port and 40 minutes drive to Qingdao airport, which is convenient in transportation logistics.
Q: Is OEM service available ?
Q: What's the delivery time and payment terms ?
A: Delivery time is based on product model and order quantity. normally it is around 7-15 working days.
The payment could paid by T/T, L/C, Western Union, Paypal, etc.
Contact Person: Kate zhu
