3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net

Certification
China Qingdao Xincheng Rubber Products Co., Ltd. certification
China Qingdao Xincheng Rubber Products Co., Ltd. certification
I'm Online Chat Now

3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net

3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net
3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net
3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net 3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net 3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net 3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net

Large Image :  3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net

Product Details:
Place of Origin: qingdao
Brand Name: xincehng
Certification: CCS LR BV SGS RS
Model Number: 1.2*2.0m
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD500-5000/pcs
Packaging Details: nude packing , deflated
Delivery Time: 7days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 40PCS per month

3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net

Description
Accessories: Shackle And Chain Length: 1.0m-9.0m
Warranty: 24 Months Usage: Pneumatic Marine Rubber Fender,Protect Boat
Color: Black,According To Customers' Requirments,Navy Grey Type: Marine Air Bag/Pneumatic Yokohama Rubber Fender
High Light:

Marine Rubber Yokohama Fender

,

3.3X6.5m Yokohama Fender

,

Tyre Net Yokohama Pneumatic Fenders

    3.3X6.5m Marine Rubber Yokohama Fender With Chain And Tyre Net

Product Description

Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5
Net Type Pneumatic Fenders
are covered with a chain net, wire net, or fiber net. Each end of longitudinal chains, wires, or fibers is linked together with one or two ring(s), which shall be connected with a guy chain or guy-rope. Usually, these nets have used tires together with rubber sleeves for additional protection to the fender body, except for fiber net which has only rubber sleeves. Chain nets last longer against corrosion, while wire nets are light and more easily repaired.

Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5
Sling Type Pneumatic Fender
is common type of Pneumatic Rubber Fenders. It is designed without chain and tyre net. So its advantage is lower weight than traditional chain and tyre net fenders. Meanwhile, Sling type pneumatic fender commonly used for some small and medium size vessels.

Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5
Features of
Pneumatic fenders:
  • Fully compliant with ISO 17357 and PIANC 2014 standards
  • Suitable for various ship-to-quay and Ship-to-Ship applications with different sizes available
  • Easy and inexpensive to install and maintain
  • Compatible with chain and tyre nets
Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5
Pneumatic fenders product
details

Xincheng Pneumatic fenders have passed ISO9001 Quality management system certificate, each fender is fully comply with ISO17357-2014 and GB/T21482-2008 international Production Standard.
Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5
Qingdao Xincheng Rubber Products Co., Ltd,
is a professional manufacturer of Ship launching airbags, Pneumatic rubber fenders, Foam filled fenders, Solid rubber fenders, Marine salvage airbags in china area. The Company was founded in 1986, which is located in the beautiful coastal city - Qingdao. Xincheng has passed the certification of I S O 9 00 1: 2 0 08, CCS, SGS, BV, LR. Nowadays, Our products have sold to around the world, such as Russia, Southeast Asia, Middle East, Africa, South America, North America, Austria and Europe. In order to meet our customer's needs, Xincheng always pursuit the good quality and supply excellent product and service for them.
Normal Size Inner Pressure:50Kpa,60%deflection Inner Pressure:80Kpa,60%deflection
(mm) (mm) (KN) (KN.M) (Kpa) (KN) (KN.M) (Kpa)
Diameter Length Reaction Force Energy Absorption Hull Absorption Reaction Force Energy Absorption Hull Absorption
500 1000 64 6 132 85 8 174
600 1000 74 8 126 98 11 166
700 1500 137 17 135 180 24 177
1000 1500 182 32 122 239 45 160
1000 2000 257 45 132 338 63 174
1200 2000 297 63 126 390 88 166
1350 2500 427 102 130 561 142 170
1500 3000 579 152 132 731 214 174
1700 3000 639 191 128 840 267 168
2000 3500 875 308 128 1150 430 168
2500 4000 1381 663 137 1815 925 180
2500 5500 2019 943 148 2653 1317 195
3300 4500 1884 1175 130 2476 1640 171
3300 6500 3015 1814 146 3961 2532 191
3300 10600 5121 3090 171 6612 4294 220
4500 7000 4660 3816 186 5866 4945 233
4500 9000 5747 4752 146 7551 6633 192
4500 12000 7984 6473 154 10490 9037 202
Note:
  1. Figures on the table comply with ISO 17357
  2. Weight of fender body and net may vary ±10%.
  3. Special sizes are available and accepted
Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5
Pneumatic Fender Packing and shipping

Xincheng Pneumatic Fender have many ways for our clients to choose, such as infate packing (with air) and deflated packing(without air),. For bigger size fenders, it had better to ship without air, aim to help you to save much transportation cost.
Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5Marine Parts Ship to Ship 50kpa Pneumatic Yokohama Fender 2.5 X 5.5


Yokohama Pneumatic Fenders

What is a pneumatic fender?
What is a Yokohama fender?
How much does a Yokohama fender weight?
What are marine fenders?
Why is it called Yokohama fender?
What are ship fenders?
