5.0m-20m Length Ship Launching Airbags Pontoon With Different Size

5.0m-20m Length Ship Launching Airbags Pontoon With Different Size
5.0m-20m Length Ship Launching Airbags Pontoon With Different Size 5.0m-20m Length Ship Launching Airbags Pontoon With Different Size 5.0m-20m Length Ship Launching Airbags Pontoon With Different Size 5.0m-20m Length Ship Launching Airbags Pontoon With Different Size

Large Image :  5.0m-20m Length Ship Launching Airbags Pontoon With Different Size

Product Details:
Place of Origin: Qingdao
Brand Name: XINCHENG
Certification: SGS CCS LR RS BV ISO9001
Model Number: 1.5*12m
Payment & Shipping Terms:
Minimum Order Quantity: 1piece
Price: $200-6000/piece
Packaging Details: deflated by tray
Delivery Time: 15days
Payment Terms: Western Union, MoneyGram, T/T, L/C
Supply Ability: 150PCS per month

5.0m-20m Length Ship Launching Airbags Pontoon With Different Size

Description
Certification: CCS,LR,BV Length: 5.0m-20m,from 1000mm To 24000mm
Working Pressure: 0.05MPa To 0.15Pa Product Name: Ship Launching Marine Air Bag,marine Rubber Airbag,ship Launching Airbag
Application: Salvage,heavy Lifting,Ship Launching,Marine/quay/dock/boat Size: Customized Size,Customer's Ruquirement
Usage: Ship Launching,landing And Slvage
High Light:

20m Length Ship Launching Airbags

,

Ship Launching Airbags Pontoon

,

5.0m Ship Launching Airbags

Boat Salvage And Landing Rubber Airbag Pontoon With Different Size

Floating Airbag is successfully developed with technological innovation on the basis of the airbag technology, which provided a convenient tool for salvage of shipwrecks, installation of pipelines and caisson culverts.



salvage airbag are widely used in marine industry of salvage and buoyancy assistance, including rescue of stranded ships or sinking ships. The maritime salvage and rescue project is sudden and time-sensitive, lifting equipment or high costs; if the salvage company adopts conventional lifting methods, it is often subject to large-scalelifting equipment or high costs; using marine airbag, the salvage company can quick and flexable to complete salvage and rescue work.



Large tonnage: As deep as 100m. Available with 50tons, 100tons, 200tons, 300tons and other standard large tonnage. Can also be customized according to customer needs.

High safety: Great puncture and abrasion resistance by using 1400-D3 high-strength nylon thread. High safety with bursting pressure being over 3 times of safety factor.

Safety valve technology: Safety valve technology is adopted to protect against over-pressure, especially in salvage effectively alleviating the buoy's relative pressure changes when floating from the bottom.

Easy & reliable operation: The Floating airbags adopts the net fixation technique - proprietary technology independently invented by FloatingAirbag. Net structure lock sleeve and the shackle type link are used to solve the problem of force transmission and prevent the buoy from sliding down, making the construction operation quite simple and convenient.

The installation: Floating airbags are easy to fix and can provide a large amount of buoyancy after inflation.

Specification Maximun Buoyancy(t) Airbag Specifications D(M)/EL(M)
0.6 0.8 1 1.2 1.5 1.8 2
F1 1T 4 2
F2 2T 7 4 3
F3 3T 11 6 4 3
F5 5T   10 6 4
F7.5 7. 5T   15 10 7 4
F10 10T     13 9 6
F12.5 12. 5T     16 11 7 5
F15 15T     19 14 8 6
F17.5 17.5T       17 10 7 6
F20 20T         11 8 6
F25 25T         14 10 8
F30 30T         17 12 10
F35 35T           14 11
F40 40T           16 13
F45 45T             14
F50 50T             16
