Boat Docking Floating Pneumatic Marine Fenders With Compressed Air

Boat Docking Floating Pneumatic Marine Fenders With Compressed Air
Boat Docking Floating Pneumatic Marine Fenders With Compressed Air
Boat Docking Floating Pneumatic Marine Fenders With Compressed Air Boat Docking Floating Pneumatic Marine Fenders With Compressed Air Boat Docking Floating Pneumatic Marine Fenders With Compressed Air Boat Docking Floating Pneumatic Marine Fenders With Compressed Air Boat Docking Floating Pneumatic Marine Fenders With Compressed Air

Large Image :  Boat Docking Floating Pneumatic Marine Fenders With Compressed Air

Product Details:
Place of Origin: Qingdao
Brand Name: XINCHENG
Certification: CCS LR BV SGS RS
Model Number: 2.5m*4.0m
Payment & Shipping Terms:
Minimum Order Quantity: 1Piece
Price: $200-12000/piece
Packaging Details: Normal packing, deflated packing
Delivery Time: 10-15days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 150piece per month

Boat Docking Floating Pneumatic Marine Fenders With Compressed Air

Description
Packing: Normal Packing Length: 0.5m~12.0m,1~9m
Feature: Aging Resistance Material: Natural Rubber
Application: STD,STS,Ships And Boats,Ship Fender,Marine/quay/dock/boat Warranty: 24 Months
Diameter: 0.5~4.5m Color: Black
High Light:

Boat Docking Floating Pneumatic Marine Fenders

,

0.5m Pneumatic Marine Fenders Compressed Air

,

CCS Pneumatic Marine Fenders Compressed Air

Floating Pneumatic Fender With Compressed Air For Ship To Dock Protection



Floating pneumatic rubber fenders are known as Yokohama fenders or inflatable pneumatic fenders. Floating pneumatic rubber fenders is made of the synthetic-cord-reinforced rubber sheet with compressed air inside to enable it to float on the water and work as a shock absorbed between two ships (ship-to-ship), or between ships and berthing structures when they come alongside each other on the water. All Marine Yokohama type floating pneumatic rubber fenders are manufactured and tested fully compliant with ISO 17357.

Fender structure

Outer Rubber

The tough abrasion resistant outer rubber is designed to protect the inner rubber and tyre-cord layers from damaging external forces. The material has mechanical properties to withstand the arduous operational conditions for which it is designed.

The diagram below shows the actual properties as specified in ISO 17357. Generally, the outer rubber is black, but other colours such as grey and off-white can be supplied upon request.

Tyre-cord Layer

Synthetic tyre-cord layers have proven to be the best option for strong, efficient reinforcement for pneumatic rubber fenders. Each layer is coated with a rubber compound on both sides that prevents contact between the layers, reducing friction and
wear during bending, compression and stretching. The same compound isolates each thread within the layer.
This greatly improves the ability of the fender to hold pressure, fatigue resistance and endurance life. Other reinforcing layer materials such as canvas have wear points that significantly reduce the life off the fender.

Inner Rubber

The inner rubber seals pressurised air inside the fender. It is usually constructed of a compound similar to that of an inner tube in a truck or car tyre to ensure a good level of air tightness.

Boat Docking Floating Pneumatic Marine Fenders With Compressed Air 0



Pneumatic Fender Applications

       In ports with extreme tidal variations

       Ship-to-ship lightering operations

       Oil & Gas (typically FSRU

       Temporary bething



How to choose the right size fender



A船舶(DWT)

A vessel(DWT)

B船舶(DWT)

B vessel(DWT)

假定接舷速度(m/s)

ASSumed speed

Access side(m/s)

有效运动能量(kJ)

Effectirve kinetic

energy



护舷尺寸(D*L)

Fender Dimension

(D*L)

300,000 200,000 0.15 1230 3.3*6.5
150,000 0.15 1030 3.3*6.5
100,000 0.15 781 3.3*6.5
200,000 150,000 0.15 882 3.3*6.5
100,000 0.15 693 3.3*6.0
85,000 0.15 618 3.0*5.0
100,000 85,000 0.17 617 3.0*5.0
50,000 0.18 511 3.0*5.0
40,000 0.20 544 3.0*5.0
50,000 40,000 0.20 425 2.5*5.5
30,000 0.22 437 2.5*5.5
20,000 0.25 443 2.5*5.5
20,000 15,000 0.27 318 2.5*4.0
10,000 0.30 309 2.2*3.5
5,000 0.35 253 2.0*3.5
10,000 5,000 0.35 212 2.0*3.5
3,000 0.40 196 2.0*3.5
1,000 0.50 137 2.0*3.0

Boat Docking Floating Pneumatic Marine Fenders With Compressed Air 1Boat Docking Floating Pneumatic Marine Fenders With Compressed Air 2Boat Docking Floating Pneumatic Marine Fenders With Compressed Air 3



Pneumatic Marine Fenders Questions

What is a pneumatic fender?
What is a Yokohama fender?
How much does a Yokohama fender weight?
What are marine fenders?
Why is it called Yokohama fender?
What are ship fenders?
