Product Details:
|
| Material: | Natural Rubber | Working Pressure: | 0.05MPa To 0.15Pa |
|---|---|---|---|
| Packing: | Standard Package,Pallet Package For Ship Launching Airbag | Product Name: | Ship Launching Marine Air Bag,marine Rubber Airbag,ship Launching Airbag |
| Technology: | High Pressure | Length: | 5.0m-20m,from 1000mm To 24000mm |
| Part: | Marine Airbag | Warranty Period: | 24 Months |
| High Light: | Natural Rubber Ship Launching Airbags,Ship Launching Airbags For Landing,Natural Rubber ship launching balloon |
||
Ship Lifting Inflatable Rubber Airbag , Ship Balloon For Landing Boats
Marine Rubber Airbag is China independent intellectual property rights of innovative products, the products are mainly applied to ship launching and landing, weight lifting, handling, installation of underwater buoyancy aid etc. Nowadays, Marine rubber airbags are widely used in the world. The Products are less limited by space, no large mechanical equipment, can shorten the working period and save the unnecessary cost. Through years of development practice, marine rubber airbag is become more safety, effective and green environmental protection.
Features
● Different airbag size stock available, quick delivery
● Provide repair kit and on site instruction
● Long time service life can be reused many times
● Wear resistance and anti aging
● Good raw material and cord fabric
● Do no harm to the environment. Time & money saving
● Need no more than air compressors, winches and ropes
● Marine airbags are much cheaper and portable than other methods
echnical Strengths:
1. Higher content Natural Rubber materials, 56%. Higher content natural rubber prove to be superior quality.
2. Gas Tightness. We design to secure the Pressure Decrease is not exceeding 5% around approximately 72 hours
3. Configuration of Airbag Layers. Layers should mean corresponding synthetic tyre cord layers and additional rubber layers combination to secure longer lifespan.
4. Breaking force of Synthetic-Tyre-Cord. Every strand is over 31kgs breaking force to reinforce the tensile strength.
Application
● For ship upgrading, conversion or new/repair launching (Ship launching airbags)
● Marine airbag for salvaging sunken ship or heavy immersed steel structure
● For hoisting and transporting heavy goods up to 10,000 tons structure on land
● For floating use purpose as improve the draft.
● Pneumatic rubber core for architecture engineering Container for storing and transporting gas and corrosive chemical liquid and pure water for voyage
● Rubber bag for ship ballast
● Rubber airbags used for culvert making.
The airbag is working under bad and poor condition, suffering from long time sunlight exposure, seawater corrosion, impurities pollution, etc. The surface of airbag must be equipped with high capability of abrasion resistance, ageing resistance, corrosion resistance.
our airbag is made of natural rubber with special ingredients and unique manufacturing method. The finished airbag could working very well under above mentioned bad and poor working condition.
| o. | Test Item | Required value | Test Method | |
| 1 | Tensile strength (MPa) | >=18 | ISO37 | |
| 2 | Elongation at break (%) | >=400 | ISO37 | |
| 3 | Hardness,º (Shore A) | 60±10 | ISO7619-1 | |
| 4 | Tear strength (N/cm) | >=400 | ISO34-1 | |
| 5 | Compression set,% (70ºC±1ºC,22h) | ≤30 | ISO815-1 | |
| 6 | After thermal aging at 70ºC±1ºC,96h | Holding of pull lengthening,% | >=80 | ISO188 |
| 7 | Holding of elongation at break,% | >=80 | ISO188 | |
| 8 | Change of hardness,º(Shore A) | ≤8 | ISO7619-1 | |
| 9 | Static ozone aging at 40ºC×96h [ozone concentration (50±5)×10-8],extension 20% | No Crack | ISO1431-1 | |
