Product Details:
Place of Origin: Qingdao
Brand Name: XINCHENG
Model Number: D 1.0m*L 2.0m
Payment & Shipping Terms:
Minimum Order Quantity: 1Piece
Price: $200-12000/piece
Packaging Details: Normal packing, deflated packing
Delivery Time: 10-15days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 150piece per month

CCS Certificate Pneumatic Marine Fenders Boat Rubber Fender With Tyres

Description
Certification: CCS BV Certification ISO17357 ISO9001,DNV,LR,CCS Warranty Period: 24 Months
Type: 80kpa Packing: Normal Packing,Nude Packing/As Requirement
Diameter: 0.5~4.5m Quality: Excellent
High Light:

CCS Pneumatic Marine Fenders

,

CCS Boat Rubber Fender

,

Pneumatic Marine Fenders With Tyres

passed CCS certificate pneuamtic marine fender , boat rubber fender with tyres



Pneumatic rubber fenders have a long and successful history of protecting vessels in mooring operations. They are ideal for permanent and semi-permanent port applications and for offshore ship-to-ship transfers. Tough and resilient, Xincheng Marine System’s fenders are fast and easy to deploy, maintaining large clearances between the hull and the jetty or other vessel. This serves to minimise damage potential during mooring.



The structure of Rubber Pneumatic Fenders:

The outer rubber layer protects the cord layer and inner layer from abrasion and other external forces. This compound has sufficient tensile and tear strength to withstand any weather condition and hard usage



The cord layers are arranged at ideal angles to hold the internal pressure and to distribute the stress evenly. The fenders cord layer is constructed by means of integrative twine technology and consists of polyamide fiber with high tensile stress, so that the fenders have unique strength and uniformity in different directions.



The inner rubber layer seals the air inside, utilizing a compound with airtight quality.Pneumatic Rubber fender description Yokohama rubber fender is intended to be used for the berthing and mooring of a ship to another ship or berthing structure. It also specifies the test and inspection procedures for high-pressure floating Pneumatic Rubber Fender.

Flange opening:The metal parts at both ends of fender,to which an air valve or safety valve can be adapted.

NOTES OF PNEUMATIC RUBBER FENDERS



1 Keep the fender away from sharp objects, in case damage the fender body.

2 Fender cannot touch with acid, oil and other organic solvent.

3 When fender not use for a long time, they should be washed to clean, dried and proper compressed air inflated. Put them in a dry , cool and ventilated area.

4 The storage area should be far away from heat source.

5 Do not put heavy objects on the fender when fender not in use.

12.6 Fender in normal usages should be checked the inner pressure every 3 months. Meanwhile, Air valve core should be replaced every 6 months.



dock fender specifications

Normal size

Diameter x Length


Initial Internal pressure 0.05MPa
Initial Internal pressure 0.08MPa



Guaranteed Energy Absorption(GEA)
Reaction Force At GEA(RF)
Hull Pressure At GEA(PR)



Guaranteed Energy Absorption(GEA)
Reaction Force At GEA(RF)
Hull Pressure At GEA(PR)
mm x mm

KN/M

KN
Kpa

Kpa

Kpa
Kpa
500x1000
6 64 132 8 83 174
600x1000
8 74 126 11 96 166
700x1500
17 137 135 24 178 178
1000x1500
32 182 122 44 235 161
1000x2000
45 257 132 63 335 174
1200x2000
63 297 126 86 386 166
1350x2500
102 427 130 140 554 170
1500x3000
153 579 132 211 751 175
1700x3000
191 639 128 263 830 168
2000x3500
308 875 128 424 1138 168
2500x4000
663 1381 137 925 1815 180
2500x5500
943 2019 148 1317 2653 195
3000x5000
965 1815 148 1341 2359 198
3300x4500
1175 1884 130 1640 2476 171
3300x6500
1814 3015 146 2532 3961 191

NOTE:1.REACTION FORCE AND ENERGY ABSORPTION TOLERANCE IS ±10%

2.WEIGHT TOLERANCE IS ±10%

3.SPECIAL SIZE CAN BE PRODUCED FOLLOW CUSTOMER'S NEED



CCS Certificate Pneumatic Marine Fenders Boat Rubber Fender With Tyres 0
