Product Details:
|
| Packing: | Normal Packing | Length: | 0.5m~12.0m,1~9m |
|---|---|---|---|
| Feature: | Aging Resistance | Material: | Natural Rubber |
| Application: | STD,STS,Ships And Boats,Ship Fender,Marine/quay/dock/boat | Warranty: | 24 Months |
| Diameter: | 0.5~4.5m | Color: | Black |
| High Light: | 4.5m Pneumatic Marine Fenders,CCS Boat Dock Fenders,Pneumatic Marine Fenders Easy To Install |
||
Sling Type Pneumatic Fender Easy To Install , Rubber Dock Fender For Boat
Fender structure
Outer Rubber
The tough abrasion resistant outer rubber is designed to protect the inner rubber and tyre-cord layers from damaging external forces. The material has mechanical properties to withstand the arduous operational conditions for which it is designed.
The diagram below shows the actual properties as specified in ISO 17357. Generally, the outer rubber is black, but other colours such as grey and off-white can be supplied upon request.
Tyre-cord Layer
Synthetic tyre-cord layers have proven to be the best option for strong, efficient reinforcement for pneumatic rubber fenders. Each layer is coated with a rubber compound on both sides that prevents contact between the layers, reducing friction and
wear during bending, compression and stretching. The same compound isolates each thread within the layer.
This greatly improves the ability of the fender to hold pressure, fatigue resistance and endurance life. Other reinforcing layer materials such as canvas have wear points that significantly reduce the life off the fender.
Inner Rubber
The inner rubber seals pressurised air inside the fender. It is usually constructed of a compound similar to that of an inner tube in a truck or car tyre to ensure a good level of air tightness.
Sling type pneumatic fenders don`t include chain tires net, but with a specially processed outer rubber double-layered cover , resulting in better resistance to operational damage.
Sling type pneumatic fender strengths:
1, First manufacturer in China being ISO17357-1-2014 Approved
2, Light and easy to re-deploy
3, Equipped with safety valve to assure safety operation.
4, Fast delivery, common size 0.5x1,1x1.5,1x2,1.5x,2x3.5 are available in stock for immediately dispatch
Sling type pneumatic fender dimension table:
| Nominal size | Internal pressure 0.05Mpa at 60% deflection | Safety-valve pressure setting | Testing pressure | |||
| Diameter | Length | Energy absorption | Reaction force | Hull pressure | ||
| mm | mm | KN-m | KN | KPa | KPa | KPa |
| 500 | 1000 | 6 | 64 | 132 | － | 200 |
| 600 | 1000 | 8 | 74 | 126 | － | 200 |
| 700 | 1500 | 17 | 137 | 135 | － | 200 |
| 1000 | 1500 | 32 | 182 | 122 | － | 200 |
| 1000 | 2000 | 45 | 257 | 132 | － | 200 |
| 1200 | 2000 | 63 | 297 | 126 | － | 200 |
| 1350 | 2500 | 102 | 427 | 130 | － | 200 |
| 1500 | 3000 | 153 | 579 | 132 | － | 200 |
| 1700 | 3000 | 191 | 639 | 128 | － | 200 |
| 2000 | 3500 | 308 | 875 | 128 | － | 200 |
| 2500 | 4000 | 663 | 1381 | 137 | 175 | 250 |
| 2500 | 5500 | 943 | 2019 | 148 | 175 | 250 |
| 3000 | 6000 | 1309 | 2387 | 148 | 175 | 250 |
| 3300 | 4500 | 1175 | 1884 | 130 | 175 | 250 |
| 3300 | 6500 | 1814 | 3015 | 146 | 175 | 250 |
| 3300 | 10600 | 3067 | 5257 | 158 | 175 | 250 |
| 4500 | 9000 | 4752 | 5747 | 146 | 175 | 250 |
| 4500 | 12000 | 6473 | 7984 | 154 | 175 | 250 |
Pneumatic Marine Fenders Questions
What is a pneumatic fender?
What is a Yokohama fender?
How much does a Yokohama fender weight?
What are marine fenders?
Why is it called Yokohama fender?
What are ship fenders?
